Model : Wave Creator

 Wave Mode : 8 modes selection and 1 night mode.
 Night Mode : automatic detection.
 Function Switch : TEST and FEED function switch.
 Cycle Range : One step is from 30 seconds to 30 minutes.
 Signal Connector : 9 pin "D" type connector.
 Status Indicator : LED lamp indicator (Red, Orange, Green)
 Output Active : 3 pumps output and 1 filter output.
 Relay Load : Total 5A/240 VAC (Resistive Load).
 Power Supply : AC110V, AC220V 50/60 Hz.
 Power Consumption : Approx. 2 Watts.
 Dimension : WV-1 : 165 x 90 x 65 mm. (6.5 x 3.5 x 2.5 inch)
                      WV-2 : 150 x 85 x 40 mm. (5.9 x 3.4 x 1.6 inch)
 Operating Humidity : Max. 90%.
 Operating Temperature : 0 to 50℃ (32 to 122℉)
